Japan Baoli E130i-BK205P LCP Plastic Material GF30 Electrical Components LCP Liquid Crystal Polymer

Name: Japan Baoli E130iBK205P LCP Plastic Material GF30 Electrical Components LCP Liquid Crystal Polymer
Brand: Baoli
Price: 7 USD

Quality Japan Baoli E130i-BK205P LCP Plastic Material GF30 Electrical Components LCP Liquid Crystal Polymer for sale

Model Number : LCP E130i-BK205P

Place of Origin : Japan

MOQ : 25KG

Price : USD7-8KG

Payment Terms : T/T

Supply Ability : 500TONS

Delivery Time : 7-15days

Packaging Details : Plastic bag/Paper bag

Brand Name : Baoli

Certification : MSDS

Product name : LCP E130i-BK205P

Elongation : 100% Virgin Material

Tensile Strength : 175MPa

Flexural Strength : 220MPA

Flexural Strain : 2.3%

Port : ShenZhen/GuangZhou,China

Contact Now

Products Description

Japan Baoli E130i-BK205P LCP Plastic Material GF30 Electrical Components LCP Liquid Crystal Polymer

LCP Japan Baoli E130i-BK205P High Temperature And High Flow Anti-Static Flame Retardant Grade 30% Glass Fiber Reinforced Electronic And Electrical Components Automotive Field Sporting Goods

LCP Japan Baoli E130i-BK205P is a 30% fiber reinforced,SMT corresponding, standard universal liquid crystal polymer, we can not imagine from the traditional plastic, with a very special structure and performance of the polymer, this material not only has different orders of magnitude mechanical strength, but also with its wall thickness thinning, The relative strength increases in specific properties, and its linear thermal expansion rate is close to that of metallic materials. In addition, although it has a high elastic modulus, excellent vibration absorption characteristics is one of its strengths, it can be said that beyond the common sense of engineering plastics, engineering plastics approaching metal.

product feature

LCP
E130i
BK205P
Product information
Other Certificates	MSDS
Part Marking Code	>LCP-GF30-FR<
Color	BK
Material Shape	Pellets
Process	Injection molding
FR	V-0
Material Attribute	30%Glass Fiber Reinforced Flame retardant
specification	·UL ·UL-746C F1 ·UL-746C F2
Application	·Automotive parts ·Connector ·E&EApplications ·SMT applications ·Home Appliances Applications ·Lighting Applications · Industrial Appl ·CPU socket ·SD card slot ·SIM card slot	·Terminal block ications
UL File NO.	E106764
Certificate	W MSDS
Physical property	Standard Value	Unit
Density	ISO 1183 1.61	g/cm³
Shrinkage Flow 80×80×1mm 60MPa	INTERNAL METHOD 0.02	%
Shrinkage xFlow 80×80×1mm 60MPa	INTERNAL METHOD 0.54	%
Water Absorption 23℃24hr 1.00mm	ISO 62 0.03	%
Hardness	Standard Value	Unit
Rockwell Hardness M(Scale)	ISO 2039 80
Mechanical behavior	Standard Value	Unit
Tensile Strength	ASTM D638 175	MPa
Elongation	ASTM D638 2.0	%
Flexural Strength	ISO 178 220	MPa
Flexural Modulus	ISO 178 15000	MPa
Flexural Strain	ISO 178 2.3	%
Charpy Notch Impact 23℃	ISO 179 35	kJ/m²
Thermal	Standard Value	Unit
HDT 1.8MPa	ISO 75 280	℃
HDT 0.45MPa	ISO 75 290	℃
Electrical properties	Standard Value	Unit
Volume Resistivity	IEC 60093 9E+15	Ω.cm
Dielectric Strength 1.0mm	IEC60243 44	KV/mm
Dielectric Strength 3.0mm	IEC60243 24	KV/mm
Dielectric Constant 1KHz	IEC 60250 4.3
Dielectric Constant 1MHz	IEC60250 3.8
Dissipation Factor 1KHz	IEC 60250 0.02
Dissipation Factor 1MHz	IEC60250 0.03
Arc Resistance	ASTM D495 130	S
CTI	IEC 60112 125	V
Flammability	Standard Value	Unit
Flame Rating All Color 0.2mm	UL94 V-0
Flame Rating All Color 0.38mm	UL94 V-0
Flame Rating All Color 0.75mm	UL94 V-0
Flame Rating All Color 1.5mm	UL94 V-0
Flame Rating All Color 3.0mm	UL94 V-0
UL	Standard Value	Unit
UL FlameRating ALL 0.2mm UL94 V-0
HWI ALL0.2mm	UL746A 4	PLC
HAI ALL0.2mm	UL746A 0	PLC
RTI Elec ALL 0.2mm	UL746B 130	℃

Japan Baoli E130i-BK205P LCP Plastic Material GF30 Electrical Components LCP Liquid Crystal Polymer

Application

Optical lighting

It used to manufacture large lampshade, protective glass, left and right eyepiece tubes of Optical instrument, etc., and can also be widely used as transparent materials on aircraft.

Electronic appliances

It used in the manufacturing of insulation connectors, coil frames, sockets, insulation sleeves, telephone shells and parts, and battery shells for mining lamps, and so on.

Mechanical equipment

It used for manufacturing various gears, racks, worm gears, worms, bearings, cams, bolts, levers, crankshafts, ratchets, and can also be used as mechanical components such as shields

Physical Property Parameter

Japan Baoli E130i-BK205P LCP Plastic Material GF30 Electrical Components LCP Liquid Crystal Polymer
